◆FDK系列是一款通用型的推拉開關，也叫滑動開關，廣泛應用于各類需要檔位控制的電動工具和小家電，如：熱風槍、電吹風等。 ◆FDK series are general type slide switches, commonly for used in power-tools and small home appliances such as Heat Guns, Hair Drvers, etc.
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4 →電氣耐久壽命 Electrical life endurance≥1E4 →最大電流 Max. current at 250V10A →接觸電阻 Contact resistance≤30m Ohm →絕緣電阻 Insulation resistance≥100M Ohm →基本介電強度 Dielectric strength of function500V →加強介電強度 Dielectric strength of reinforced500V →環境溫度 Ambient temperature0°C~85°C →阻燃等級 FlammabilityUL 94V-0 →防護等級 Protection typeIP40 →適用于II類防護器具 Suitable for appliances of protection class II
