產品描述Product description
◆MK05系列是一款專用型的交流線路板組件，具有軟啟動等功能，廣泛應用于各類手持式電動工具,如：150和180角向磨光機、拋光機、型材切割機、斜切鋸等。
◆MK05 series are one special type AC PCB Assembly, with soft start function, etc. Commonly for used in portable power-tools such as 150mm and 180mm Angle Grinders, Polisher Grinders, Cut-off machines or Miter Saws, etc.
產品特征Features
◆可選帶以下功能 Optional following function types:
→斷電重啟保護功能 Restart Protection(X)
→軟啟動功能 Soft Start Function(S)
→過流保護功能 Over Current Protection Function(CP)
→過溫保護功能 Over Temperature Protection Function(TP)
技術數據Technical data
→電氣耐久壽命 Electrical life endurance≥5E4
→最大電流 Max. current at 250V15A
→最大電流 Max. current at 127V24A
→絕緣電阻 Insulation resistance≥7M? Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced500V
→環(huán)境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→導線端子 Wire lead terminals
電氣參數和認證 Electric Rating and Certification
